Binary™ 260 Series 4K HDR Switch with IR - 3x1

Binary™ 260 Series 4K HDR Switches with IR

These simple and cost-effective switchers deliver 4K HDR HDMI content reliably and effectively between sources and one display. Transmit 4K@60Hz 4:4:4 video over HDMI while utilizing dealer-centric features like front panel and IR control.

Full 4K HDR Content

This Binary extender transmits 4K@60Hz 4:4:4 video over HDMI for effective and reliable content.

Ultra-Small Form Factor and Easy Mounting

A small form factor means you can mount this extender almost anywhere with ease, allowing you to spend more time delivering the best possible experience for your customer.

IR & RS-232 Control with Drivers Available

The B-260-SWTCH-4x1 switcher IR control requires an external IR receiver, which is not included. The IR input is compatible with all Episode IR receivers, including E-IR-RCVR-TUBE, EE-IR-RCVR-SM, and EE-IR-RCVR-TT. The required IR remote control is included for your convenience.

Built-In ESD and Surge Protection, Thermal Reliability

Intelligent circuit design, perfected through extensive hardware testing, has resulted in a robust product with excellent ESD and surge protection that exceeds CE Level 3 standards. During development, every connection was tortured with an ESD gun and a lightning simulator. They were hit with ESD at 15KV and surges up to 1600V. More importantly, though, they each lived to tell about it!

Ideal for Professional Environments

Share content from multiple laptops to multiple screens in a boardroom or design a state-of-the-art command-and-control center with the B-260-SWTCH-4X1. Display the latest graphics in crisp 4K60 (4:4:4) and control the video routing via an IR input.
