| Image Sensor Type | CMOS |
|---|
| Ingress Protection Rating | IP66 |
|---|---|
| NDAA Compliant | Yes |
| TAA Compliant | Yes |
| Number of Sensors | 4 |
|---|
| Maximum Operating Temperature | 131.00°F |
|---|---|
| Minimum Operating Temperature | -58.0°F |
| Operating Humidity | 1 |
| Longest Shutter Speed | 1/25 Second |
|---|---|
| Shortest Shutter Speed | 1/15000 Second |
| ADI Part Number | PB-NDM7702A |
|---|---|
| Brand Name | Bosch |
| Country of Origin | TW |
| Manufacturer | Bosch |
| Manufacturer Part Number | F.01U.389.262 |
| Packaged Quantity | 1 |
| Product Line | FLEXIDOME multi |
| Product Model | NDM-7702MP-A |
| Product Name | NDM-7702 mP-A Fixed dome12 mPMP3 mP.7 mP-7 mP.7 mPmm IP66 mP |
| Product Series | 7000i |
| Product Type | Camera |
| Network (RJ-45) | Yes |
|---|
| Focal Length | 3.7-7.7mm |
|---|---|
| Lens Included | Yes |
| Maximum Focal Length | 7.70mm |
| Environmental Certification | China RoHS, EU RoHS, EU WEEE, WEEE |
|---|---|
| Environmentally Friendly | Yes |
| Features | Automatic White Balance, Back Light Compensation (BLC), Cross Line Detection, Day/Night, Defog, Dynamic Noise Reduction, Enter/Exit Detector, Privacy Masking, Region of Interest, SD Card Local Storage, Tamper Detection, Wide Dynamic Range |
| Impact Protection Rating | IK10 |
| Indoor/Outdoor | Indoor |
| Package Contents | 1 2 -pin power connector, 1 8 -pin Audio and I/O connector, 1 Camera, 1 Mounting plate, 1 RJ-45 punch-through aid, 1 TR20 Allen key, 2 M20 rubber grommets |
| Remote Management | Yes |
|---|
| Color | White |
|---|---|
| Durability | Dust Resistant, Impact Resistant, Snow Resistant, Vandal Resistant, Waterproof, Wind Resistant |
| Form Factor | Dome |
| Height | 4.00" |
| Weight | 14.00lb |
| Input Voltage | 24V AC |
|---|
| Diameter | 7.00" |
|---|---|
| Mount Type | Surface Mount |
| Recording Formats | H.264, H.265 / HEVC |
|---|---|
| Storage Type | SD Card |
| Connectivity Technology | Wired |
|---|---|
| Effective Camera Resolution | 12MP |
| Field of View | Horizontal, Vertical |
| Field of View (Horizontal) | 81.9° |
| Field of View (Vertical) | 59.80° |
| Maximum Aperture | f/1.9 |
| Maximum Frame Rate | 30.0fps |
| Minimum Focal Length | 3.00mm |
| Optical Zoom | 2.1x |
| Video Formats | H.264 / AVC, H.265 / HEVC, Motion JPEG |
| Wide Dynamic Range | Yes |
| Maximum Resolution | 1280 x 720 |
|---|
