HDMI over IP PoE Seamless Transceiver 4K/30

Description

HDMI over IP PoE Seamless Transceiver, 4K30

The HDMI over IP PoE Seamless Transceiver (500860), 4K/30 allows HDMI source equipment to be extended locally up to 330ft (100m) at up to 4K @ 30Hz resolution via Cat5e/6 cable and is compatible with the MuxLab 500861 Transceivers to support point-to-point, point-to-multipoint and multipoint-to-multipoint configurations, Video Wall and Multiview capabilities in a low bandwidth expandable and cost effective manner, without the need to install dedicated cabling systems. The exceptionally low bandwidth requirements of this device combination allows for streaming audio/video content over a local network, over WiFi, and over the Internet for distributed installations spread throughout the globe. The Transceiver accepts a 4K video @ 30Hz and streams the content to an H.264/H.265 Receiver to be displayed on a 4K monitor. The device supports PoE (PD) and may be powered by a PoE (PSE) Ethernet Switch.

• Supports up to 4K @ 30Hz video streams
• H.264/265 video codec, excellent for LAN and Internet transmission
• High image quality and ~80ms latency
• Supports seamless switching
• This unit is a Transceiver and can be used as a Transmitter, as a Receiver, or as both simultaneously
• Supports Video Wall
• Supports Multiview with up to 16-windows per screen
• Supports image rotation, scrolling text, banner, etc. RS232, RS485, USB, Relay and I/O for remote control of end devices
• PoE powered, via PoE (PSE) Ethernet Switch
• Managed via Muximus Network Controller (500813)
