Description
96W Hard Wired Power Interface for Lumaris LED Tape strips
- Compatible with RRL-MWCL-WH & RRL-TWCL-WH (and HWL- versions)
- Includes 3x barrel-to-terminal adapters for use with **L-TWCL-WH
- Powers up to 3 Lutron Lunaris LED Tape Lights
- Class 2 separation - Barrier provided for in the wiring compartment
- Operating 120v~/277v 50/60 Hz
- Output load range: 2w to 96w at high end
- https://assets.lutron.com/a/documents/3691301_eng.pdf
Requires:
-
Tunable White LED Tape Light: (**)
-
Soft White (1800K to 3000K)
- LU-LU-T05-SW (5m / 16.4 ft)
- LU-LU-T30-SW (30m / 96.4 ft)
-
Daylight (2500K to 5000K)
- LU-LU-T05-DT (5m / 16.4 ft)
- LU-LU-T30-DT (30m / 98.4 ft)
-
RGB + Tunable White LED Tape Light: (***)
- LU-T05-RT-IN (5m / 16.4ft)
- LU-T30-RT-IN (30m / 98.4ft)
-
Wireless Controller:
- LU-RRL-TWCL-WH (**)
- Maximum Total Tape Length per Controller: 16.4 FT (5m) (Must be split into parallel runs, each no more than 16.4 ft (5 m), see spec sheet for details:
- LU-RRL-MWCL-WH (***)
- Maximum Total Tape Length per Controller: 32.8 FT (10m) (Must be split into parallel runs, each no more than 16.4 ft (5 m), see spec sheet for details:
-
Wiring and Mounting Hardware
- LU-LU-CK1-6W (6-pin wire-to-tape connectors (qty 10)
- LU-LU-WK1-6W (6 x 22 AWG cable - 50 ft (15.2m)
- LU-LU-MK1 (0.394 in (10mm) surface mounting clips (qty 20)
-
LED Tape Extrusions
- LU-LU-SR1-K, LU-LU-SR2-K, LU-LU-SR3-K*, LU-LU-45S-K, LU-LU-45T-K, LU-LU-RR1-K*, LU-LU-MI1-K
- * SR3 and RR1 extrusions do not fit the 6-pin wire/tape connectors. Connections inside the SR3 and RR1 must be through the reel's pre-soldered wire
Lutron’s tape light solution enhances scene control, providing a simple and seamless way to integrate accent lighting into connected home projects.
Powered by ultra-reliable Lutron Clear Connect–Type X wireless technology, Lutron tape light controllers seamlessly integrate with the Lutron platform, including controls, apps, programming software, and Lutron Connect cloud services.
A complete Lutron tape light system includes field-cuttable LED tape, a wireless controller with built-in LED drivers, high-reliability punch connectors, dedicated wiring, and a power supply or interface. For optimal performance and aesthetics, install the tape light within Lutron LED tape extrusions.
