Provision-ISR 128 Channel 16MP Facial Recognition NVR with Alarms, Raid Support, and NDAA Compliance

Out of Stock

Provision-ISR 128 Channel 16MP Facial Recognition NVR with Alarms, Raid Support, and NDAA Compliance

Name: Provision-ISR 128 Channel 16MP Facial Recognition NVR with Alarms, Raid Support, and NDAA Compliance
Brand: Provision-ISR
SKU: PV-NVR16-128RFAN-3U
Price: 6468.0 CAD
Availability: OutOfStock

$6,468.00

Description

Summary

Provision-ISR NVR16-128RFAN(3U) is an easy-to-install solution suitable for big-sized installations (up to 128 channels). The device features 24 alarm inputs + 4 alarm outputs and provides you with everything you need for a trouble-free CCTV project. All hardware components, including the Raid, are validated to meet the demands for reliable high-definition surveillance. This model complies with NDAA demands and ensures that your devices are cyber-protected round the clock with the integrated Check Point Quantum IoT Nano agent that provides an advanced threat prevention layer against the common attack vectors at runtime.

Features

Video:

Input: 128 Channel Support
Output: HDMI1 (8K 30/60Hz, 4K, 1080P, 1280×1024) (When the resolution of HDMI1 output is 8K, HDMI2 is unavailable) HDMI2: 4K, 1080P, 1280×1024, 1024×768 HDMI3: 4K, 1080P, 1280×1024, 1024×768 HDMI4: 1080P, 1280×1024, 1024×768 VGA: 1080P 1280×1024, 1024×768 (VGA and HDMI1 output the same video source)

Bandwidth:

Incoming: 768Mbps
Outgoing: 768Mbps

Decoding Support:

H.265S/H.265+/H.265/H264

Analytics:

Camera Tampering, DDA2 With Object Classification, Line Crossing (DDA / Pixel Based), Sterile Area (DDA / Pixel Based), Object Monitoring, Object Counting (DDA), Crowd Gathering, People Intrusion, Smart Search, Face Recognition (Up to 16 CH), LPR, Thermal.
Advanced Face Recognition Mode: Supports 4 Non-AI IPCs and performs face detection and recognition.

Recording:

128CH 16MP Real-Time
FPS: 3200 (PAL) / 3840 (NTSC)

Playback:

Local: 16Ch Simultaneously
Remote: 16Ch Simultaneously

Audio:

Input: 1CH + IPC Inputs
Output: 1CH + IPC outputs IP Speaker
Compression: G.711A/G.711U
Two Way Audio

Alarm:

Input: 24+IPC
Output: 4+IPC

Storage:

16 supports Hot-Swap
HDD Max Capacity: 10TB
E-SATA Support: 2
Total HDD Max Capacity: NaNTB
RAID: Yes (0/1/5/6/10)

USB Port:

2 USB 2.0 Port + 1 USB 3.0 Port

Network:

2 x RJ-45: 10/100/1000Mbps Each

Remarks:

The following features are based on firmware 1.4.12_78966_RD250520 and are subject to firmware version changes.

Specifications

Specifications for: PV-NVR16-128RFAN-3U: Provision-ISR 128 Channel 16MP Facial Recognition NVR with Alarms, Raid Support, and NDAA Compliance
3rd Party Cyber Protection
General	Quantum IoT Nano agent by Check Point™
Protection Methods	Shell injection protection, File Monitor, Import-Table Protection, Dynamic-Memory Protection
NDAA Compliant
NDAA Compliant	Yes
Video
Video Input	128Ch Over Network
Output	HDMI1 (8K 30/60Hz, 4K, 1080P, 1280x1024) (When the resolution of HDMI1 output is 8K, HDMI2 is unavailable) HDMI2: 4K, 1080P, 1280×1024, 1024×768 HDMI3: 4K, 1080P, 1280×1024, 1024×768 HDMI4: 1080P, 1280×1024, 1024×768 VGA: 1080P 1280×1024, 1024×768 (VGA and HDMI1 output the same video source)
View Mode	Independent*, Up to 32ch Per Monitor (When enabled, NVR based analytics are disabled)
Fish-Eye Dewarp	VMS + Local (1 at a time) + Web (1 at a time)
Decoding Format	H.265 / H.265+ / H.265S / H.264
Decoding Capabilities	1Ch – 16MP ; 4Ch – 12MP ; 9/16Ch – 1MP ; 32Ch – D1 ; 64Ch – D1
Audio
Audio-specs-Input	1CH RCA (Linear, 1kΩ) + IPC Inputs
audio-specs-Output	1CH RCA (2.0 Vp-p, 1 kΩ) + IPC outputs IP Speaker
Compression	G.711A/G.711U
Two Way Audio	Yes
Analytics
Supported Analytics	Camera Tampering, DDA2 With Object Classification, Line Crossing (DDA / Pixel Based), Sterile Area (DDA / Pixel Based), Object Monitoring, Object Counting (DDA), Crowd Gathering, People Intrusion, Smart Search, Face Recognition (Up to 16 CH), LPR, Thermal. Advanced Face Recognition Mode: Supports 4 Non-AI IPCs and performs face detection and recognition.
Analytics Channels (IPC Based)	128Ch (Requires supporting IPC)
Analytic Channels (NVR Based)	Up to 8Ch DDA1 (Sterile Area/Line Crossing) or Up to 4Ch Face Detection + Recognition or Up to 16Ch Face Recognition (or their combinations) Supported Resolution: 1MP – 4K
Face Recognition Rate	36 Faces per second (16Ch supported)
Bandwidth
Incoming	768Mbps
Outgoing	768Mbps
Record/ Main Stream
Real-Time Recording	128CH 16MP Real-Time
Record Type	Video / Video + Audio
Recording Modes	Schedule, Manual, Motion, Sensor, Analytics, POS and all of its combinations
16MP	3840FPS(NTSC)/3200FPS(PAL)
12MP	3840FPS(NTSC)/3200FPS(PAL)
8MP	3840FPS(NTSC)/3200FPS(PAL)
5MP and lower	3840FPS(NTSC)/3200FPS(PAL)
Master stream over network	Up to 128CH@Recording Resolution
Substream
Resolution substream	Depends on IPC
Remote view
Max Channel View	640Ch (Limited to Outgoing Bandwidth Capacity)
Remote Applications
User Access	128 Users online with Professional Authority Management
Mobile App	Provision Cam2 for iOS/Android
PC/Mac Software	Ossia VMS Standard / Enterprise
Plug-in free Web-Browser	Chrome, FireFox, Safari, Edge, Opera. (All Limited to 4Ch Live View / Playback) *P2P WEB connetion always requires Plugin
Plug-in based Web-Browser	Internet Explorer
Playback
Local	16Ch
Remote	16Ch
Search Mode	DDA Object, Smart Search, LPR, Time-Slice, Time, Event, POS
Backup
USB	2 USB 2.0 Port + 1 USB 3.0 Port
Backup Format	AVI (Unencrypted) / Private Format (Encrypted / Unencrypted)
Alarm
Alarm-in	24+IPC
Alarm-out	4+IPC
Storage
HDD	16 supports Hot-Swap
HDD Max Capacity	10TB
E-Sata Support	2
Total HDD Max Capacity	NaNTB
RAID	Yes (0/1/5/6/10)
PTZ
Connection	Via Network
Supported Controls	Pan, Tilt, Zoom, Preset, Cruise, Scan, Iris, Focus
RS-485	Yes (C06 Keyboard Connection)
Network
Ethernet	2x1000/100/10Mbps self-adaptive Ethernet interface with Fault Tolerance / Dual Network Configuration
Protocols	TCP/IPv4/IPv6, DHCP, DDNS, NTP, SMTP, SSL/TLS, UPnP, P2P, RTSP, FTP, HTTPS, 820.1X, SNMP, Auto Report Input + Output (Ossia VMS)
ONVIF	Full Device Support (Profile T/G, ONVIF Version 20.12)
PoE
PoE Ports	N/A
Speed	N/A
Standard	N/A
CCTV Mode	N/A
Total Power	N/A
Max. Power Output (Per Ch.)	N/A
Others
Power Supply	AC100-240V
Power consumption (No HDD)	50W
Dimension	W437xD483xH143mm
Operation Temperature	0°C~50°C
