| Power Source |
100 - 240 V AC, 50/60 Hz ( use of the supplied AC adapter) |
| Power Consumption |
72 W |
| Current Consumption |
Max. 3 A DC ( when 24 V DC is supplied from the accessory AC adapter) |
| Carrier Frequency |
Reception: Audio channel 1: 7.35 MHz
Audio channel 2: 8.10 MHz
Audio channel 3: 8.55 MHz
Audio channel 4: 9.15 MHz
Control channel: 6.45 MHz
Transmission: Audio channel: 1.95 MHz |
| Input |
MIC -60 dB ( *2) , 600 Ω, unbalanced, ¢6.3 mm phone jack ( 2P)
AUX -20 dB (*2) , 10 kΩ, unbalanced, ¢6.3 mm phone jack (2P) |
| Output |
LINE: -10 dB (*2), 1: 0 kΩ, unbalanced, ¢6.3 mm phone jack (2P)
REC: -10 dB ( *2 ), 10 kΩ, unbalanced, RCA pin jack
HEADPHONES: ¢3.5 mm mini jack ( 3P: monaural) |
| Equalizer Input/Output |
Input: -20 dB ( *2 ), 10 kΩ, unbalanced, RCA pin jack
Output: -20 dB ( *2 ), 10 kΩ, unbalanced, RCA pin jack |
| Number of Connectable Chairman/Deleqate Units |
64 units |
| Number of Connectable Infrared Transmitter /Receiver Units |
Up to 4 units ( with the use of distributor, up to 16 units connectable
when they are all TS-905, and up to 12 units when they are all TS-907, or TS-905 and TS-907 are used in combination) |
| Infrared Transmitter /Receiver I/0 Terminal |
BNC jacks |
| External Control Connection Terminal |
D-sub connector (9P, male)/USB-B selectable |
| LED Indicator |
Audio signal receiving indicators 1 - 4 CH, Data signal receiving indicator,
External control priority indicator, External control communication indicator,
Battery indicator ( flashes when a Chairman/Delegate unit's battery nears complete discharqe ), Short-circuit indicator |
| Function Switch |
Number of open microphones setting switch: 1 /2/3/ 4
Mic-off setting switch: TIME OUT ON/OFF
Speech priority selector switch:
FIRST ( First-in-first-out priority)
LATEST ( Last-in-first-out priority)
FIRST: FIXED NEXT: LATEST (Priority fixed for the first unit, and last-in- first-out priority for all other subsequent units.)
FBS switch: AUTO/OFF /EXT |
| Operatinq Temperature |
0 °c to +40 °c (32 °F to 104 °F |
| Operatinq Humidity |
90 %RH or less ( no condensation) |
| Finish |
Panel: Surface-treated steel plate, black, 30 % qloss, paint |
| Weiqht |
2.7 kq (5.95 lb) |
| Accessory |
AC adapter (Cord length: 1.8 m (5.91 ft) DC cord, and 2 m (6.56 ft) detachable
AC cord)( *3) ··1 |
| Option |
Rack mounting bracket: MB-TS920 |
