| Specifications for: CY-NVR4K-16P-4TB-V2: Cymbol 16MP H.265 NVR 16CH 16PoE 8/2 Alarm 2 SATA w/4TB HDD | ||
|---|---|---|
| VIDEO/AUDIO INPUT | IP Video Input | 16-ch |
| Two-way Audio Input | 1-ch, RCA | |
| NETWORK | Incoming Bandwidth | 320Mbps |
| Outgoing Bandwidth | 160Mbps | |
| Remote Users | 128 | |
| Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP | |
| Browser | IE(IE10/11) for Windows, Firefox (version 52.0+) for Windows Chrome(version 45+) for Windows, Edge(version 79+) for Windows | |
| VIDEO/AUDIO OUTPUT | HDMI/VGA Output | HDMI: 4K (3840x2160/30Hz), 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| VGA: 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz | ||
| Recording Resolution | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | |
| Audio Output | 1-ch, RCA | |
| Audio Compression | G.711A, G.711U | |
| Synchronous Playback | 16-ch | |
| Liveview display | 1/4/6/8/9/16 | |
| Corridor Mode Screen | 3/4/5/7/9/10/12/16 | |
| SNAPSHOT | FTP/Schedule/Event Snapshot | 4-ch snapshot, up to D1 resolution |
| DECODING | Decoding format | Ultra 265/H.265/H.264 |
| Liveview/Playback | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | |
| Capability | Ultra 265/H.265: 2 x 16MP@30, 2 x 12MP@30, 4 x 4K@30, 6 x 5MP@30, 8 x 4MP@30, 10 x 3MP@30, 16 x 1080P@30, 32 x 960P@25 H.264: 2 x 16MP(4800 x 2688)@30, 2 x 12MP@30, 2 x 4K@30, 4 x 5MP@30, 6 x 4MP@30, 8 x 3MP@30, 14 x 1080P@30, 30 x 720P@30, 32 x D1 |
|
| HARD DISK | SATA | 2 SATA interface |
| Capacity | Up to 16TB for each disk (The max HDD capacity varies with environment temperature) | |
| SMART | VCA Detection by Camera | Vehicle Detection, Intrusion Detection, Cross Line Detection, Enter Area, Leave Area,Temperature Detection(Fire Detection, Smoking Detection, Temperature Measurement, Smoke and Fire Detection), UMD(Ultra Motion Detection), Video Metadata, Traffic Monitoring |
| VCA Search | Motor Vehicle Search, Non-Motor Vehicle Search, Human Body Search, General Search, People Counting Report | |
| People counting | People Flow Counting, Crowd Density Monitoring | |
| Smart Intrusion Prevention (SIP) by Camera | 8-ch | |
| GENERAL ALARM | General Alarm | Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Motion, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection |
| Alert Alarm | IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal | |
| EXTERNAL INTERFACE | Network Interface | 1 RJ45 10M/100M self-adaptive Ethernet Interface |
| USB Interface | Rear panel: 1 x USB2.0, 1 x USB3.0 | |
| RS232/RS485 | NA/1-ch | |
| Alarm In/Alarm Out | 8-ch/2-ch | |
| POE | Interface | 16 RJ45 10M/100M self-adaptive Ethernet Interface |
| Max Power | Max 30W for single port | |
| Max 240W in total | ||
| Supported Standard | IEEE 802.3af/at | |
| GENERAL | Power Supply | 100 ~ 240 V AC |
| Power Consumption: ≤ 10W (without HDD) | ||
| Working Environment | -10°C ~ + 55°C (+14°F ~ +131°F), Humidity ≤ 90% RH (non-condensing) | |
| Dimensions (W×D×H) | 380mm × 322mm × 53mm (15.0”×12.7”×2.1") | |
| Weight (without HDD) | ≤2.6kg (5.73lb) | |
| CERTIFICATION | Certification | CE, FCC, UL, RoHS, WEEE |
| CE | EN 55032: 2015, EN 61000-3-3: 2013, EN IEC 61000-3-2: 2019, EN 55035: 2017 | |
| FCC | Part15 Subpart B, ANSI C63.4 | |
Download CY-NVR4K-16P-4TB-V2 Spec Sheet
